LDT-800LM Laser Floor Grinding / Milling Machine is the first intelligent floor processing equipment in floor industry. Mainly used in automation counter system channel flatness processing. It can meet the ground flatness rigid demand and decorative ground leveling process. This machine has a high degree of automation, reduce the skill requirement of operator. It can largely improve floor preparation standard and lead the floor grinding machinery developing into intelligent, integration and efficiency.
LDT-800LM Laser Floor Grinding / Milling Machine is the most advanced laser automatic grinding equipment in the world. When the machine is being operation, the ground flatness can be measured and analyzed. Through data collection and analysis, it can do super-flat grinding automatically and reach to 4m±1mm flatness. For the completed construction ground, it can automatically display the ground information graph. The machine equip with 800mm work area gear grinding head for easy to construction in the channel of automation counter system and improve machines’ reliability.
Technical Parameters:
| Model | LDT-800LM Laser Floor Grinding / Milling Machine |
| MOTOR | 11KW 15HP |
| INVERTER | 15KW 20HP |
| VOLTAGE | 3 phase 220V/380V/460V |
| AMPERE | 30A-40A |
| WORKING WIDTH | 31.50 in / 800 mm |
| WEIGHT | 1543 lbs / 700 kg |
| LENGTH | 86.61 in / 2200 mm |
| WIDTH | 31.50 in / 880 mm |
| HEIGHT | 51.18 in / 1300 mm |
| REVOLUTION | 0-150 rpm |
| ROTATION | 0-1200rpm |
