1 The blade has good sharpness and high efficiency at the process of cutting,meanwhile,it has a long lifespan
2 Good cutting result:smooth cutting,flat surface and even size
3 Stable cutting,narrow cutting gap,stone waste reduction 4M-Shape segment is easy for diamond opening
| Diameter(mm) | Steel core(mm) | Segment size(mm) | Segment Number | Shape | Application |
|---|---|---|---|---|---|
| 900 | 5.0 | 24×7.5×13(15) | 64 | Z(straight) | Sandstone |
| 1000 | 5.0 | 24×7.5×13(15) | 70 | Z(straight) | Sandstone |
| 1200 | 5.5 | 24×8.0×13(15) | 80 | Z(straight) | Sandstone |
| 1400 | 6.0 | 24×8.5×13(15) | 92 | Z(straight) | Sandstone |
| 1600 | 7.0 | 24×9.5×13(15) | 108 | Z(straight) | Sandstone |
| 1800 | 7.5 | 24×10×13(15) | 120 | Z(straight) | Sandstone |
| 2000 | 8.0 | 24×11×13(15) | 128 | Z(straight) | Sandstone |
| 2200 | 8.0 | 24×11×13(15) | 132 | Z(straight) | Sandstone |
| 2500 | 9.0 | 24×12.5×13(15) | 140 | Z(straight) | Sandstone |
| 2700 | 9.0 | 24×12.5×13(15) | 140 | Z(straight) | Sandstone |
Other specifications are available upon request.
